UL498 UL486A-B Conductors Damage Degree Test Machine 2 Stations
| Applied Standards: | UL486A-B, UL498, IEC 60884-1,etc | Test Stations: | 2 Stations |
| Rotate Rate: | 10±2 RPM, 9±1 RPM, | Test Height: | 260, 280,300,320mm |
| Gyration Diameter: | 75mm, 76mm | Bushing Diameter: | 6.5, 9.5, 13, 14.5mm |
| High Light: | UL486A-B Degree Test Machine,Conductors Damage Degree Test Machine |
||
UL498 UL486A-B Conductors Damage Degree Test Machine 2 Stations
Product Introductions:
This conductors damage degree testing machine is also called the test apparatus for checking damage degree of wire which confirms to standards UL486A-486B and UL498 SD5.3 test method B, etc. This test machine is used for judging whether the design and the structure of the clamping screw terminal is correspondent with the requirement of non over-damage to the wire. Besides, it is also used to check whether the clamping screw terminal can bear the stress during the process of normal usage.
The testing times can be preset before the test, and the testing machine stops automatically with the alarm when the testing times are reached.
Technical Parameters:
| Power supply | Match client's local power supply requirements |
| Standards | UL498, UL486A-B, IEC 60884-1, etc. |
| Stations | Two stations, synchronization |
| Test speed | 10±2 r/min, 9±1 r/min |
| Gyration Diameter | 75mm/76mm |
| Test height | 260mm, 280mm, 300mm, 320mm, can be customized |
| Test times | 0-9999, preset |
| Bushing holes |
Diameter: 6.5mm, 9.5mm,13mm,14.5mm, can be customized |
