IEC60335-1 Vacuum Cleaner Hoses Current-Carrying Hoses Flexing Test Device 5 Station

MOQ: 1
Price: Customized
Standard Packaging: Plywood Case
Delivery Period: 30 Days
Payment Method: T/T
Supply Capacity: 10 sets per month
Details Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Sinuo
Certification
Calibration Certificate(Cost Additional )
Model Number
SN2121-5
Flexing Angle:
0-180° (Presettable: ±30°, ±45°, ±60°, ±90°)
Flexing Speed:
0-60 Cycles/min, Presettable
Test Stations:
5 Stations, Synchronized
Test Count:
0-999999 Cycles, Presettable
Drive Method:
Servo Motor + Precision Reduction Gear
Control Method:
PLC Control, Touchscreen Operation
Product Description



IEC60335-1 Vacuum Cleaner Hoses Current-Carrying Hoses Flexing Test Device 5 Station







Product information:



This device meets the standard of IEC60335-1:2004,IEC60335-2-2:2009,IEC60312-1:2010.It is used to assess the mechanical performance of vacuum cleaner hoses under left and right flexing.The device uses a motor-driven mechanism to perform reciprocating flexing oscillation testing of the current-carrying hose.



Samples and Limitations:



Vacuum cleaner hoses,Water-suction cleaning appliance hoses,Washing machine water hoses





Equipment Structure and Features:



The reduction motor controls the oscillating structure for reciprocating motion, with left and right flexing angles adjustable directly via the touchscreen. The machine stops automatically after reaching the preset test count.



IEC60335-1 Vacuum Cleaner Hoses Current-Carrying Hoses Flexing Test Device 5 Station 0



Technical parameters:



Operating Environment

Power supply: AC220V±10% / 50-60Hz

Operating temperature: 0-40℃

Humidity: 30%-90%
Control Method PLC control, touchscreen operation
Test Stations 5 stations, synchronized
Drive Servo motor + precision reduction gear
Flexing Angle 0-180° (Presettable: ±30°, ±45°, ±60°, ±90°)
Flexing Direction Selection IEC60335-1 Vacuum Cleaner Hoses Current-Carrying Hoses Flexing Test Device 5 Station 1IEC60335-1 Vacuum Cleaner Hoses Current-Carrying Hoses Flexing Test Device 5 Station 2IEC60335-1 Vacuum Cleaner Hoses Current-Carrying Hoses Flexing Test Device 5 Station 3IEC60335-1 Vacuum Cleaner Hoses Current-Carrying Hoses Flexing Test Device 5 Station 4
Flexing Speed 0-60 cycles/min, presettable
Test Count 0-999999 cycles, presettable
Load Weights 10N, 20N
Equipment dimensions approximately 1300×400×1550 (mm) (W×D×H)
Equipment weight 150kg







IEC60335-1 Vacuum Cleaner Hoses Current-Carrying Hoses Flexing Test Device 5 Station 5IEC60335-1 Vacuum Cleaner Hoses Current-Carrying Hoses Flexing Test Device 5 Station 6

IEC60335-1 Vacuum Cleaner Hoses Current-Carrying Hoses Flexing Test Device 5 Station 7
