Coupler Pulling Test Apparatus Connector To Pull Test For Household IEC 60320-1

Coupler Pulling Test Apparatus Connector To Pull Test For Household IEC 60320-1

MOQ: 1
Price: Customized
Standard Packaging: Plywood
Delivery Period: 20 days
Payment Method: T/T
Supply Capacity: 20 Sets Per Month
Detail Information
Place of Origin
China
Brand Name
Sinuo
Certification
Calibration Certificate (Cost Additional)
Model Number
SN2104
Test Station:
Single
Power Supply:
AC 220V, ±50Hz
Humidity:
30%-90%
Working Temp.:
5-35℃
Flexible Cable:
40±2 Mm
Pulling Force:
0-100N
Pulling Method:
50 Times In One Direction
Appliance Input Socket:
Optional Gauge
Minimum Order Quantity:
1
Price:
Customized
Packaging Details:
Plywood
Delivery Time:
20 days
Payment Terms:
T/T
Supply Ability:
20 Sets Per Month
High Light:

IEC 60320-1 Coupler Pulling Test Apparatus

,

Household Coupler Pulling Test Apparatus

Product Description



Coupler Pulling Test Apparatus Connector To Pull Test For Household IEC 60320-1



Standards For Coupler Pulling Test Apparatus:



IEC60320-1:2021 "Appliances couplers for household and similar general purposes- Part1:General requirements" clause 23.3 and figure 19.



Test principle For Coupler Pulling Test Apparatus:



The connector is inserted into an appliance inlet of a type corresponding with the connector to be tested and complying with the relevant standard sheet, a spring force mechanism is used to apply lateral force to it.



Technical parameters For Coupler Pulling Test Apparatus:



Test station Single station
Flexible cable bending height 40±2 mm,adjustable
Power supply AC 220V, ±50Hz
Working temperature 5-35℃
Humidity 30%-90%
Pull force range 0-100N
Pulling method 50 times in one direction and then 50 times in the opposite direction
Cable selection and corresponding pull value table Coupler Pulling Test Apparatus Connector To Pull Test For Household IEC 60320-1 0
Appliance input socket Optional gauge according to requirements


Structure For Coupler Pulling Test Apparatus:



The connector test should be equipped with an appliance inlet of a type corresponding with the connector to be tested and complying with the relevant standard sheet.



Coupler Pulling Test Apparatus Connector To Pull Test For Household IEC 60320-1 1
