| MOQ: | 1 |
| Price: | Customized |
| Standard Packaging: | Plywood |
| Delivery Period: | 1 Month |
| Payment Method: | T/T |
| Supply Capacity: | 20 Sets Per Month |
IEC60335-2-7 Integrated Door Endurance Testing Equipment For Washing Machines
Standards For Washing Machine Door Endurance Testing Equipment:
Standard:Conforms to IEC60335-2-7:2016 clause 18.101, IEC60335-2-11:2016 clause 20.101.
Technical Parameters For Washing Machine Door Endurance Testing Equipment:
| Power Supply | AC220V±10%/ 50 Hz, power 3KW or match client’s power supply requirements |
| Test Stations | 2 independent stations, one is for tumble washing machine with door, the other is for pulsator washing machine with lid |
| Control Method | PLC intelligent integrated control, 7-inch humanized touch interface operation |
| Drive Mode | Servo motor drive |
| Clamping Method for Specimen | Vacuum suction cup, pneumatic |
| Door/Lid Opening or Closing Speed | 0-360°/s(1.5m/s), can be preset |
| Door/Lid Opening or Closing Angle | 0-130°, can be preset |
| Test Times | 0-999999times, can be preset |
| Door/Lid Opening or Closing Force | 0-200N, can be preset (the opening force value is only for the pull test when the interlock device is actuated to lock the door) |
| Load Voltage | 0-250V, adjustable |
| Auxiliary Action Mechanism | Washing machine starts pressing cylinder (can be customized) |
| Test Contents |
Tumble washing machine door interlocking device endurance test (IEC 60335-2-7 clause 18 and IEC 60335-2-11 clause 20.101) Pulsator washing machine lid interlocking device endurance test (IEC 60335-2-7 clause 18 and IEC 60335-2-11 clause 20.101) |
Application For Washing Machine Door Endurance Testing Equipment:
It is used to test the durability of the interlocking device of washing machine door or lid, and the force test when the interlock is actuated, so as to verify the reliability of the interlocking device; also used to assist other tests for repeated opening and closing operations of the washing machine door or lid.
Test Principle For Washing Machine Door Endurance Testing Equipment:
Electric tumble dryer, electric washing machine (including pulsator and tumble type).
Structure For Washing Machine Door Endurance Testing Equipment:
The equipment combines of electrical control cabinet (including load voltage regulating device), frame and manipulators. There are two testing station, one is for tumble washing machine with door, the other is for pulsator washing machine with lid, the two workstations can process testing independently.
Equipment dimensions: approx.: (W*D*H) 2500 * 1200 * 1500 (mm)
Equipment weight: 180kg
|
|
