IEC60898-1 RCBO Mechanical 40mm Height Shock Test Machine
  • name
  • name
  • name
  • name

IEC60898-1 RCBO Mechanical 40mm Height Shock Test Machine

MOQ: 1
Price: Customized
Standard Packaging: Plywood
Delivery Period: 30 Days
Payment Method: L/C, , T/T, Western Union, MoneyGram
Supply Capacity: 1 set per month
Details Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Sinuo
Certification
Calibration Certificate (Cost Additional)
Model Number
SN2506
Applied Standard:
IEC 60898-1
Load Output:
0-999999s
Coil Spring:
Elastic Coefficient 25N/mm
Turntable Angle:
Can Be 4-90°rotation Fixed
Drop Height:
40mm
Test Station:
Single
Highlight:

electromagnetic testing services

,

emc testing laboratory

Product Description



IEC60898-1 RCBO Mechanical 40mm Height Shock Test Machine





Standards & Information:



The test equipment conforms to the standard requirements of IEC 60898-1:2015 Electrical accessories-Circuit-breakers for overcurrent protection for household and similar installations-Part 1: Circuit-breakers for a.c.operation.



The test operates by using a motor-driven cam mechanism to lift the mounting plate holding the circuit breaker, which is then released to fall freely onto a metal stop plate equipped with a coil spring (elastic coefficient: 25N/mm) to absorb the impact. This process is repeated 50 times in succession. The sample is then rotated 90 degrees using a rotary platform, and the procedure is repeated in each of the remaining three orientations, completing a total of 200 impact cycles to fully assess mechanical durability.





Features:

  1. PLC-based intelligent control system with touchscreen interface and servo motor drive for high-precision operation.

  2. The drop height is accurately defined by the cam’s eccentric distance, ensuring consistent and repeatable results.

  3. Utilizes a customized helical spring from Yiheda with a specific elastic coefficient for optimal performance.

  4. The rotary platform supports four 90° incremental rotations, enabling comprehensive multi-directional impact testing of circuit breakers to simulate real-world usage scenarios.





Technical Parameters:



Model SN2506
Test station Single
Electrical control method PLC intelligent integrated control, man-machine touch interface operation
Drive Mode Motor drive mechanism cam
Coil Spring Elastic coefficient 25N/mm
Base A, Platform B, Plank C Hardwood, painted black
Drop height 40mm
Turntable Can be 4-90°rotation fixed
Weights 100g*10pcs, 150g*5pcs, 200g*5pcs
Number of tests 0-999999 times, touch screen preset
Load output 0-999999s, touch screen preset
Dimension 900mm×600mm×1350mm
Weight About 110 KG
Power supply AC380V±10% 50Hz, 1kVA


Sample Display:

IEC60898-1 RCBO Mechanical 40mm Height Shock Test Machine 0

IEC60898-1 RCBO Mechanical 40mm Height Shock Test Machine 1
