PLC Controlled IPX8 Immersion Test Equipment with Stainless Steel Pressure Tank

Water Ingress Testing Equipment
December 22, 2025
Category Connection: Water Ingress Testing Equipment
Chat Now Contact Us
Tags:
#rain test chamber #waterproof test equipment #Water Spray Test Equipment
Brief: Need quick answers about practical use? This video highlights the essentials. Watch as we demonstrate the PLC Controlled IPX8 Immersion Test Equipment in action, showing you how it verifies waterproof performance for various products according to IEC 60529:2013 standards. You'll see the stainless steel pressure tank setup, the intuitive touch screen interface for configuring tests, and the automated pressurization process that keeps terminal blocks dry during immersion testing.
Related Product Features:
  • PLC-controlled operation with user-friendly touch screen interface for easy test parameter configuration.
  • Stainless steel pressure tank construction ensures durability and corrosion resistance for IPX8 testing.
  • Automatic water supply and pressure control system maintains consistent test conditions.
  • Air pressurization system keeps electrical terminal blocks dry during immersion testing procedures.
  • Dual pressure protection with mechanical safety valve and program control for enhanced safety.
  • Screw rod cover mechanism facilitates easy sample placement and removal from the test chamber.
  • Modular wire withdrawal system simplifies maintenance and component replacement.
  • Separate pressure gauges provided for accurate calibration and verification of test parameters.
FAQs:
  • What standards does this immersion test equipment comply with?
    This PLC Controlled IPX8 Immersion Test Equipment is designed to meet IEC 60529:2013 standards for IPX8 waterproof testing, ensuring reliable verification of product protection against continuous water immersion.
  • What types of products can be tested with this equipment?
    The equipment is suitable for testing electronic and electrical products, automotive components, motorcycle parts, household appliances, seals, and lighting fixtures to verify their waterproof performance under immersion conditions.
  • How is the test chamber prepared for immersion testing?
    The test chamber is filled with a sugar water solution (68% sugar, 32% water) to simulate immersion conditions. After assembling the connector and loading samples, the interior is pressurized with approximately 25 lines drawn to the exterior for testing.
  • What safety features are included in the equipment?
    The equipment includes dual pressure protection with a mechanical safety valve set at 0.55 MPa protection limit and program control, along with a 0.5 grade pressure sensor for accurate monitoring and safety during testing operations.
