Axial Force Of Edson Caps Test Equipment IEC 62560 Luminaries Test Equipment
  • name
  • name
  • name
  • name

Axial Force Of Edson Caps Test Equipment IEC 62560 Luminaries Test Equipment

MOQ: 1
Price: Negotiable
Standard Packaging: Plywood Case
Delivery Period: 30 Days
Payment Method: T/T
Supply Capacity: 20 Sets Per Month
Details Information
Product Description
Detail Information
Place of Origin
China
Brand Name
Sinuo
Certification
Calibration Certificate (Cost Additional)
Model Number
SN9926
Power Supply:
AC 220V, 50Hz
Force Range:
0-500N
Force Speed:
0-300mm/min
Control Method:
PLC Control
Resolution:
0.1N
Stroke:
0-500mm
Samples:
Edison Lamp Cap
Test Gauge:
According Table 4
Highlight:

IEC 62560 Luminaries Test Equipment

,

Axial Force Luminaries Test Equipment

,

Luminaries Test Equipment

Product Description


Axial Force Of Edson Caps Test Equipment IEC 62560 Luminaries Test Equipment





Product information:



The test equipment is designed and manufactured according to IEC 62560 clause 9.4. It is used for checking the axial strength of the Edison cap.





Technical parameters:


Samples and restrictions Edison lamp cap
Test purpose Used to detect the mechanical strength of caps of Edsion lamps.
Test principle

Use a motor-driven pressure plate to apply a certain pressure to the center of the lamp cap, so that the test lamp cap exerts force vertically along the axis of the fluorescent lamp until the force reaches a constant value for 1 minute and then released.

Axial Force Of Edson Caps Test Equipment IEC 62560 Luminaries Test Equipment 0
Structure and features Single-arm force applying mechanism, force value can be set, LCD screen operation and display
Power supply AC220V,50Hz
Main performance indicators
Test station Single station
Electrical control method LCD interface operation and display, with force value curve
Drive mode Motor driven
Specimen clamping method

Mechanical clamping, the clamping point position is adjustable

Axial Force Of Edson Caps Test Equipment IEC 62560 Luminaries Test Equipment 1
Force apply range 0-500N, resolution 0.1N, accuracy 1%F.S. It can achieve achieve 80N and 120N required by IEC62560:2015.
Test gauge

7006-6-1,7006-27H-1,7006-27F-1,7006-27B-1,7006-27-7, each one piece

Accordingly following table:

Axial Force Of Edson Caps Test Equipment IEC 62560 Luminaries Test Equipment 2
force application speed 0-300mm/min
Stroke 0-500mm,resolution: 0.01mm
Result display With force value-time curve, the test results can be output through a micro printer

Axial Force Of Edson Caps Test Equipment IEC 62560 Luminaries Test Equipment 3Axial Force Of Edson Caps Test Equipment IEC 62560 Luminaries Test Equipment 4

Axial Force Of Edson Caps Test Equipment IEC 62560 Luminaries Test Equipment 5
