IEC60335-1 Clause 20.1 Ф800mm Steel Inclined Plane Button Control
| Applied Standard: | IEC60335-1 | Applied Clause: | Clause 20.1 |
| Test Station: | Single | Electrical Control Method: | Button Control |
| Drive Mode: | Drive Mode | Countertop Diameter: | Ф800mm |
| High Light: | Steel Inclined Plane,Button Control Steel Inclined Plane,IEC 60335-1 Steel Inclined Plane |
||
IEC60335-1 Clause 20.1 Ф800mm Steel Inclined Plane Button Control
Product Information:
This inclined plane complies with the standard requirements of IEC60335-1 Clause 20.1, IEC 60950: 2013 clause 4.1, IEC 60065:2014 clause 19.1, etc. The test device consists of a work surface and an angle adjustment device, is suitable for all types of audio and video products, home appliances, kitchen appliances and similar electrical appliances to do mechanical stability test. The test sample is placed on the plane to test its mechanical stability performance by different angle inclined.
Technical Parameters
| Model |
Surface Diameter |
Surface Material |
Angle Range |
Load Capacity |
Rotation Method |
Rotation Speed |
Remark |
| SN1105A | 800mm | High-quality spray steel plate |
0-30° Stepless Adjustable |
80kg |
Electric |
1r/min | Round table |
