Clause 8.6.2 And 8.6.5 Steel Inclined Plane Electrical Appliance Testing Equipment IEC 62368-1
| Applied Standard: | IEC 62368-1 | Clause: | 8.6.2, 8.6.5 |
| Test Station: | Single | Electrical Control Method: | Button Control |
| Drive Mode: | Drive Mode | Countertop Diameter: | Ф800mm |
| High Light: | Clause 8.6.2 Electrical Appliance Testing Equipment,Inclined Plane Electrical Appliance Testing Equipment,IEC 62368-1 Electrical Appliance Testing Equipment |
||
IEC 62368-1Clause 8.6.2 and 8.6.5 Steel Inclined Plane Electrical Appliance Testing Equipment
Product Information:
This inclined plane complies with the standard requirements of IEC 62368-1:2018 clause 8.6.2, 8.6.5, IEC60598-1 clause 4.13.4 (c), IEC60335-1 Clause 20.1, IEC 60950: 2013 clause 4.1, IEC 60065:2014 clause 19.1, etc. The test device consists of a work surface and an angle adjustment device, is suitable for all types of audio and video products, home appliances, kitchen appliances and similar electrical appliances to do mechanical stability test. The test sample is placed on the plane to test its mechanical stability performance by different angle inclined.
Technical Parameters
| Applied Standard | IEC 62368-1 |
| Clause | 8.6.2, 8.6.5 |
| Test Station | Single |
| Electrical Control Method | Button control |
| Drive Mode | Motor driven |
| Countertop Diameter | Ф800mm |
| Countertop Material | High quality sprayed steel plate |
| Angle Adjustment Range | 0-30°, manually adjustable |
| Rotation Mode | Electrical control, automatically 1r/min |
| Bearing Capacity | 100kg |
