High Performance Shielding Effectiveness EMC Test Equipment EN 50147 Electromagnetic Shielded Room

High Performance Shielding Effectiveness EMC Test Equipment EN 50147 Electromagnetic Shielded Room

MOQ: 1
Price: Customized
Standard Packaging: Plywood
Delivery Period: 60 Days
Payment Method: L/C, , T/T, Western Union, MoneyGram
Supply Capacity: 1 set per month
Detail Information
Place of Origin
China
Brand Name
Sinuo
Certification
Calibration Certificate (Cost Additional)
Model Number
SN662
Test Samples:
Electronic And Electrical Equipment
Room Size:
Customized
Power Supply:
380V ± 10% 50 / 60Hz
Applied Standards:
EN 50147, CISPR17, Etc.
Minimum Order Quantity:
1
Price:
Customized
Packaging Details:
Plywood
Delivery Time:
60 Days
Payment Terms:
L/C, , T/T, Western Union, MoneyGram
Supply Ability:
1 set per month
High Light:

emc test systems

,

emc testing laboratory

Product Description

EN 50147 Electromagnetic Shielded Room High-performance Shielding Effectiveness EMC Test Equipment​



Standards & Clauses:



EN50147 “High-performance shielding room shielding effectiveness of the measurement method”
CISPR17 “passive radio interference filter and suppression element suppression characteristics of the measurement method”
CISPR25 “Radio disturbance characteristics of vehicles, boats and internal combustion engines Limits and methods of measurement for the protection of vehicular receivers”
ISO11452-4 “Road vehicles with narrowband emitted electromagnetic energy electronic interference components test method BCI large current injection method”
GB/T 50719-2011 “Electromagnetic shielding room engineering specifications”
GB/T 12190 “Electromagnetic shielding room shielding effectiveness of the measurement method”



Samples and Restrictions:



The electromagnetic shielding room is used to isolate the electromagnetic environment indoors and outdoors to ensure the normal operation of indoor electronic and electrical equipment. Mainly used for conducted emission test, conducted immunity test, EMI discontinuous interference test, etc.



Application:



Electrical appliances and electronic devices, including in-car electronic systems, generate a certain amount of electromagnetic waves at work that may interfere with surrounding equipment or be received by specialized equipment.
The electromagnetic shielding room is used to isolate the electromagnetic environment indoors and outdoors, which can prevent external electromagnetic interference from entering the room to affect the test, and can limit the electromagnetic leakage of indoor high-power high-frequency equipment to prevent the influence to people and equipment around. It is the ideal venue for EMC testing.



Test Principle:



Electromagnetic shielding room is mainly used for automotive electronic conduction emission (CE) test, transient conducted immunity test, bulk current injection method (BCI) test, stripline method test, etc.



Structure:



Power supply: 380V ± 10% 50 / 60Hz
Ambient temperature: 5 °C ~ +40 °C, there should be no high concentration of dust, corrosive gas, flammable and explosive objects



Typical Application​:



Typical Application Conducted Emission Test (CE)
Discontinuous Interference Test (CLICK)
Conducted Immunity Test (CS)
RF Disturbance Power Test (RFP)
Tricyclic Antenna Radiation Test (MFI)
Inductive Current Density Test(EMF)
Harmonic currents, voltage fluctuations and flicker (Harmonic & Flicker)

Shielding effectiveness SE (According to EN50147-1):

Field Source Frequency (MHz) Shielding Effectiveness (dB)
Magnetic Field 0.014 ≧70
Magnetic Field / Electric Field 0.1 ≧90
Magnetic Field / Electric Field 1 ≧100
Electric Field 100 ≧110
Electric Field 450 ≧110
Electric Field 950 ≧100
Electric Field 3000 ≧100
Electric Field 18000 ≧100
