IEC 62133 Lithium Battery Test System with Explosion Proof Chamber

IEC 62133 Lithium Battery Test System with Explosion Proof Chamber

MOQ: 1
Price: Negotiation
Standard Packaging: Plywood
Delivery Period: 30 Days
Payment Method: T/T
Supply Capacity: 10 Sets Per Month
Detail Information
Place of Origin
China
Brand Name
Sinuo
Certification
Calibration Certificate (Cost Additional)
Model Number
SN552B
Applied Standards:
IEC 62133-7
Chamber Size:
500*500*500mm
Outer Box Material:
Cold-rolled Plate
Inner Box Material:
Stainless Steel
Power Supply:
AC 220V±10%, 50Hz
Weight:
Approx 200kg
Warranty:
1 Year
Meterial:
Metal
Minimum Order Quantity:
1
Price:
Negotiation
Packaging Details:
Plywood
Delivery Time:
30 Days
Payment Terms:
T/T
Supply Ability:
10 Sets Per Month
High Light:

Testing Rotating Spits Stationary Ovens

,

4.5kg Load Spits Stationary Ovens

Product Description



IEC 62133 Lithium Battery Test System with Explosion Proof Chamber



Product information For Lithium Battery Test System with Explosion Proof Chamber:



Battery overcharge and over-discharge explosion-proof box is mainly used for battery overcharge and over-discharge, charge and discharge test, the battery is placed in the explosion-proof box, external charge and discharge test equipment, the operator and the instrument for protection.



Technical Parameters For Lithium Battery Test System with Explosion Proof Chamber:



Equipment size

Test chamber size per layer: 500*500*500 (D*W*H),( Three zones structure, can be customized.

Outer box size: 710*780*2060mm (W*D*H)

Equipment Material

Outer box: 1.5MM thick cold-rolled plate and high-temperature double-sided baking paint treatment.

Inner box: SUS # 304 stainless steel, thickness 1.00MM thick.

Box load-bearing capacity The bottom load capacity is not less than 150KG, the second/third layer load capacity is not less than 50KG
Equipment box door

Single door, double door, inner box door is made of stainless steel, and add silicone strip to tighten, open visual observation window on the front

The door is connected to the box by strong hinges, while each door adds an explosion-proof hinge, the right end of the chain is fixed in the latch side to prevent the explosion-proof box and door separation, effectively protecting the safety of testers

Observation Window Double tempered glass, tempered glass thickness of 10MM, double tempered glass between the addition of steel wire grid in the explosion can do traction, while preventing the glass explosion when the glass splash injury testers situation. Observation window sealing using 3M glass adhesive for sealing
Box protection The test chamber is fully laminated with Teflon tape inside to effectively prevent corrosion, insulation, flame retardant and easy to clean.
Wire loading port Each layer of the box on the left and right sides of each open a round loading line mouth, Ф50MM diameter, easy to test the connection line through
Exhaust Each layer of the box back are installed with exhaust fans and leave the exhaust guide (diameter 100MM), can be connected to the laboratory powerful extraction fan
Lighting

Each layer of the box is installed with lighting device, convenient to observe the specimen.

Individual test panels to control lighting and exhaust in each test chamber.

Heat insulation protection Insulation design between each layer can avoid mutual influence test.
Weight Approx 200kg
Power supply AC 220V±10%, 50Hz

IEC 62133 Lithium Battery Test System with Explosion Proof Chamber 0
