IEC 62368-1 Annex T.6 Figure T.1 Steel Ball Horizontal And Vertical Impact Test Device

IEC 62368-1 Annex T.6 Figure T.1 Steel Ball Horizontal And Vertical Impact Test Device
IEC 62368-1 Annex T.6 Figure T.1 Steel Ball Horizontal And Vertical Impact Test Device IEC 62368-1 Annex T.6 Figure T.1 Steel Ball Horizontal And Vertical Impact Test Device IEC 62368-1 Annex T.6 Figure T.1 Steel Ball Horizontal And Vertical Impact Test Device IEC 62368-1 Annex T.6 Figure T.1 Steel Ball Horizontal And Vertical Impact Test Device

Large Image :  IEC 62368-1 Annex T.6 Figure T.1 Steel Ball Horizontal And Vertical Impact Test Device

Product Details:
Place of Origin: China
Brand Name: Sinuo
Certification: Calibration Certificate (Cost Additional)
Model Number: SN2202
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Standard Exporting Plywood Case
Delivery Time: 30 Days
Payment Terms: L/C, T/T
Supply Ability: 15 Sets Per Month
Detailed Product Description
Applied Standard: IEC 62368-1 Applied Clause: Annex T.6 Figure T.1
Lift Mode: Electric Impact Method: Vertical Or Horizontal
Drop Height: 0.4-1.5m Adjustable Impact Energy: G=mgH, Can Achieve 0.5J, 1J,2J, 3.5J
High Light:

IEC 62368-1 Impact Test Device

,

Annex T.6 Impact Test Device

,

Steel Ball Vertical Impact Test Device



IEC 62368-1 Annex T.6 Figure T.1 Steel Ball Horizontal and Vertical Impact Test Device



Product Information:

Standard: Conforms to IEC 62368-1:2018 Annex T.6 Figure T.1 and T.9, IEC 60950-1: 2013 Clause 4.2.5, IEC 60065:2014 clause 12.1.4 fig.8, 12.7.3.5, IEC 60598-1 Clause 4.13.4a, etc.

Application: This device is suitable for drop impact test for equipment enclosure.

Test sample: Luminaries, Audio, video and similar electronic apparatus, Information technology equipment

Feature: Equipment can carry out test in two forms of vertical drop and swing impact



Technical Parameters:

Applied standard IEC 62368-1
Applied clause Annex T.6
Impact steel ball Diameter 50mm±1mm, 500±25g
Impact method Vertical impact and horizontal impact methods can be switched
Drop height 0.4-1.5m adjustable
Lift mode Electric
Clamping release mode Ball is attracted and released by electromagnet
Impact energy G=mgH, can achieve 0.5J, 1J,2J, 3.5J
Power supply 220V, 50Hz
